Triomix (S) 2 self-loading mixer wagon

    The Triomix silage cutter and feed mixer is an economically appealing machine. This self-loading mixer wagon permits just a single person and a single tractor to perform the entire loading, mixing and discharge process. The Triomix features a moving cutting or stationary knife and a purpose-designed cutting and loading system that guarantees minimum wastage during cutting and which maintains the structure of the feed. Thanks to its compact form and the excellent view to the rear from the tractor, the robust Triomix is very easy to manoeuvre.

    attributes

    Capacity 12 m³
    Discharge type Front discharge
    Model Selfloading

      Explanation of abbreviations

      • VL = Front discharge
      • H = High discharge unit
      • L = Low discharge unit
      • B = Synthetic conveyor belt
      • K = Conveyor chain
      • C = Curved conveyor chain
      • ZK = Side discharge doors
      • X = Heavy Duty

      Share

      Photos

      Video

      Standard features

      • Two vertical Twin Stream augers (15 mm flighting / 18 mm wings)
      • One restrictor blade
      • U-form frame with hydraulic cutting knife system (2 1200) our stationary knives (S2 1200)
      • Adjustable and reversible drawbar with 50 mm drawbar eye
      • Wide angle PTO-shaft
      • Front conveyor belt (w=0,75 m)
      • Tandem axle with 4 single wheels
      • Trioform auger knives short
      • Hydraulic loading system
      • Electric operation
      • Hydraulic brake system
      • Wear ring
      • Sealing brush on loading board

      Technical specifications

      Triomix 2  2 1200 S2 1200
      Capacity m3 12 12
      Length m 6.42 6.42
      Width m 2.25 2.25
      Height m 2.76 2.73
      Width of U-shaped cutting plate m  1.84 2.20
      Discharge height  0.84 0.84
      Maximum cutting heigth m 4.00 4.00
      Tractor power requirement HP (kW) 79 (58) 79 (58)
      Tyre size (4 x) 235/75
      R 17.5

      235/75
      R 17.5
