Triomaster S silage grab

    The Triomaster S is a silage shear grab with a fixed blade, capable of shearing effortlessly through silage, without moving the stack. The silage wall therefore remains intact and is not compressed, pulled loose, lifted or vibrated loose, as can occur with other existing silage cutting techniques. The risk of overheating is thus limited to a minimum. The Triomaster S is available in volumes of 2 and 3 m3.


    Capacity 2-3 m³



    Standard features

    • Perfect silo facing
    • U-form frame with stainless steel replacable stationary cutting knives
    • Cutting by hydraulic pressure
    • Electric controlled parallel system
    • High loading capacity
    • With toothed sealing
    • No spillage in front of the silo clamp or in transit
    • Suitable to load all other commodities

    Technical specifications

    Triomaster S  S 200  S 300
    Capacity m3 2,2 4,1
    Prescribed cutting volume m3 2 3
    Length m 1,67 2,14
    Width m 2,23 2,66
    Height m 1,89 2,37
    Silage cutting height m 2,37 2,93
    Cutting frame width m 1,83 2,21
    Cutting depth m 0,45 0,45
    Net weight in kg.  1.420 2.150
    Max. payload kg.  1.200 1.800
    Min. lifting capacity of the loading vehicle kg.  3.000 8.500
    Min. gross weight of the loading vehicle kg.*  7.000 11.000
    Min. required hydraulic capacity 25 l/min., 170 bar 25 l/min., 170 bar
    Maximum permitted hydraulic capacity 160 l/min. 160 l/min.
    Required electrical connection  12 of 24 V 12 of 24 V

    * Indication of loading vehicle's gross weight based on an ideal connection and the maximum payloads described above.
