Solomix 2 stationary feed mixer for Biogas

    The challenge facing every biogas producer is to generate as much energy as possible with a minimum amount of input. Generating a positive yield is not always easy, however. A major factor is the type of delivery system used to transport the residual feed to the digester. Trioliet supplies stationary mixers with vertical augers and capacities ranging from 10 to 80 m³. The Solomix 2 STAT Biogas features 2 augers and is available in volumes ranging from 12-40 m³.

    attributes

    Capacity 12-40 m³

    Photos

    Video

    Standard features

    • The machine is equipped with one discharge door as standard.
    • Two mixing augers with planetary drive mechanism driven by one or two electric motor(s)
    • Trioform auger knives
    • Mixing augers with 15 mm winding / 18 mm auger wings (1200 - 2000)
    • Mixing augers with 22 mm winding / 25 mm auger wings (from 2400)
    • Four height-adjustable supports with the option to install weigh bars for the various set-up options
    • Two manually operated counter knives
    • Detachable auger bases (from 2400)

    Technical specifications


    Solomix 2 Biogas
    1200 1600 2000 2400 3000 3200 4000
    Capacity m3 12 16 20 24 30 32 40
    Length m 4.21 4.6 5.2 5.72 5.72 6.56 6.56
    Length (incl. motor) m 5.24 5.59 6.28 -- -- -- --
    Width m 2.15 2.29 2.44 2.44 2.44 2.80 2.80
    Width (incl. motoren) m -- -- -- 3.67 3.67 3.84 3.84
    Height m * 2.55 - 2.85 2.84 - 3.14 2.84 - 3.14 2.77 - 3.07 3.36 - 3.66 2.75 - 3.05 3.35 - 3.65
    Nett weight kg ** 3.400 4.300 5.400 6.400 7.600 9400 10.000
    Maximum payload kg. 6.000 8.000 10.000 12.000 15.000 16.000 - 20.000 **** 20.000
    Number of auger knives  4 5 5 6 6 9 9
    Auger diameter mm Ø 1500 Ø 1700 Ø 1960 Ø 2200 Ø 2200 Ø 2660 Ø 2660
    Required electrical installation Soft-start device / Freq. drive Soft-start device / Freq. drive Soft-start device / Freq. drive Soft-start device / Freq. drive Soft-start device / Freq. drive Soft-start device / Freq. drive Soft-start device / Freq. drive
    Required electric motor power kW*** 15 22 30 2x15 2x18,5 2x22       2x30 **** 2x30

    * The height of the supports can be adjusted by 300 mm
    ** Nett weight = excl. motor frame and electric motor
    *** Indicated required electric motor power valid up to max. payload
    **** Only in combination with a heavy-duty drive line
