Solomix 2 ZKX Feed mixer
The Solomix 2 ZKX is a robust feed mixer with two vertical augers and a hydraulic discharge door on both sides. The trailed feed mixer combines a powerful construction with the best mixing quality and the lowest total cost of ownership. The feed mixer is suitable for intensive use under harsh conditions for both large and small farms. The machine is available in sizes from 24- 36 m³. Use the links to discover more about the unique features of our feed mixers or read about the importance of the correct loading sequence here.
Standard features
- Two Heavy Duty Twin Stream augers (22 mm flighting / 25 mm wings) with Trioform auger knives short
- Dual Flow: improved shape of the mixing tub and offset inserts
- Two restrictor blades
- Wide-angle PTO shaft with shearbolt (1 3/4 - 20 tractor connection)
- Adjustable and reversible drawbar
- Manual adjustable discharge chutes
- Adjustable low drawbar with 50 mm drawbar eye (European standard) (2800-3600)
- Reduction gearbox standard with cooling system
- Two large double wheels
- Tandem axle with 4 single wheels (2400L-3200) or 8 dual wheels (3600)
- Two side discharge doors with rounded edges for better discharge in front
- Flexible and spacious side door covers
- Directly operated by tractor hydraulics
- Hydraulic brake system with parking brake
- Wear ring
- New platform with stairs and windows
- New in height adjustable arm for weighing indicator
- New protection and cover for hydraulic hoses and wires with storage possibility
Technical specifications
| Solomix 2 ZKX | 2400L | 2800 | 2400L ZKX-T | 2800 ZKX-T | 3200 ZKX-T | 3600 ZKX-T |
|---|---|---|---|---|---|---|
| Capacity m3 | 24 | 28 | 24 | 28 | 32 | 36 |
| Length m | 7,72 | 7,79 | 7,72 | 7,79 | 8,23 | 8,27 |
| Width m | 2,78 | 2,77 | 2,78 | 2,77 | 2,97 | 3,02 |
| Height m | 3,02 | 3,35 | 3,04 | 3,44 | 3,44 | 3,57 |
| PTO RPM | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 |
| Tractor power requirement HP (kW) | 120(88) | 130(95) | 120(88) | 130(95) | 150(110) | 177(130) |
| Tyre size | 275/70 R 22.5 (4 x) | 315/80 R 22.5 (4 x) | 435/50 R 19.5 (4 x) | 385/65 R 22.5 (4 x) | 385/65 R 22.5 (4 x) | 275/70 R 22.5 (8 x) |
Alternative height dimensions are available on request. Ask your dealer about the available options.
