Solomix 2 ZK Feed mixer

    The renewed Solomix 2 ZK is a compact feed mixer with two vertical augers and a hydraulic discharge slide on both sides. This trailed mixer wagon is suitable for both large and small-scale livestock breeders and is available in volumes from 12-28 m³. The Solomix 2 ZK is available in a range of different heights and various discharge options are available for the Solomix 2 series, including to the front (VL) or rear (AL) of the mixer. Learn more about the unique features of our Solomix feed mixers by clicking the link.

    attributes

    Capacity 12-28 m³
    Discharge type Side discharge door
    Model Trailed
    Strawblower No

      Explanation of abbreviations

      • VL = Front discharge
      • H = High discharge unit
      • L = Low discharge unit
      • B = Synthetic conveyor belt
      • K = Conveyor chain
      • C = Curved conveyor chain
      • S = Vold down chain conveyor
      • ZK = Side discharge doors
      • X = Heavy Duty

      Photos

      Video

      Standard features

      • Two Twin Stream augers (22 mm fighting / 25 mm wings)
      • Two side discharge doors with rounded edges for better discharge in front
      • Manual adjustable discharge chutes
      • Flexible and spacious side door covers
      • Two restrictor blades
      • Trioform auger knives short
      • Wide-angle PTO shaft with 1 3/8"-6 profile
      • Two large single wheels
      • Adjustable and reversible drawbar with 40 mm drawbar eye (European standard)
      • 540 RPM drive line (1600L-2400) or a 540/1000 RPM drive line (2400L-2800)
      • Window in front of the mixing tub
      • Directly operated by tractor hydraulics
      • Wear ring
      • Walking tandem axle with four single wheels (ZK-T)
      • Hydraulic brake system with parking brake (ZK-T)
      • New platform with stairs and windows
      • New in height adjustable arm for weighing indicator
      • New protection and cover for hydraulic hoses and wires with storage possibility

      Technical specifications

      Solomix 2 ZK1200140015001600 1600L180020002000L220024002400L26002800
      Capacity m312141516161820202224242628
      Length m6,056,126,446,486,916,957,007,387,037,077,467,507,54
      Width m2,292,262,392,382,492,492,492,702,542,542,782,772,77
      Height m2,51***2,742,64***2,772,69***2,83***3,022,70***3,123,232,973,143,25
      PTO Drive540540540540540540540540540540540/1000540/1000540/1000
      Tractor power requirement HP (kW)82(60)82(60)85(62)85(62)102(75)102(75)102(75)112(82)105(77)109(80)120(88)125(92)140(103)
      Tyre size (2x)400/45
      L 17.5
      400/45
      L 17.5
      400/45
      L 17.5

      400/45
      L 17.5

      435/50
      R 19.5

      435/50
      R 19.5

      435/50
      R 19.5

      435/50
      R 19.5

      435/50
      R 19.5
      435/50
      R 19.5

      435/50
      R 19.5
      275/70
      R 22.5
      275/70
      R 22.5

      .

      Solomix 2 ZK-T1600L
      ZK-T
      1800
      ZK-T
      2000
      ZK-T
      2000L
      ZK-T
      2200
      ZK-T
      2400
      ZK-T
      2400L
      ZK-T
      2600
      ZK-T
      2800
      ZK-T
      Capacity m3161820202224242628
      Length m6,816,957,007,387,037,077,467,507,54
      Width m2,462,492,492,702,542,542,782,772,77
      Height m2,73***2,87***3,062,74***3,163,273,023,143,26
      PTO Drive540540540540540540540/1000540/1000540/1000
      Tractor power requirement HP (kW)102(75)102(75)102(75)112(82)105(77)109(80)120(88)125(92)140(103)
      Tyre size (4x)435/50
      R 19.5
      435/50
      R 19.5
      435/50
      R 19.5
      435/50
      R 19.5
      435/50
      R 19.5
      435/50
      R 19.5
      435/50
      R 19.5
      435/50
      R 19.5
      435/50
      R 19.5


      Alternative height dimensions are available on request. Ask your dealer about the available options.
      *** Note: side door will rise 22 cm (1200 ZK) respectively 10 cm (1500 ZK) above the tub when completely opended.
      *** Note: side door will rise 19 cm (1600L ZK), 7 cm (1800 ZK) respectively 20 cm (2000L ZK) above the tub when completely opened.
