Solomix 2 VLX Feed mixer

    The Solomix 2 VLX is a heavy-duty feed mixer with two vertical augers. The feed mixer is available in four different discharge options, such as a wider cross conveyor belt or a (curved or height adjustable) cross conveyor chain. This trailed feed mixer wagon is extremely well-suited to dairy farms that wish to process large quantities of feed in a short space of time. The wagon is available in sizes from 24 - 36 m³. Whether processing small or large quantities, feed is mixed quickly to produce a mix of uniform structure. Click here for an overview of the unique characteristics of our feed mixers or read about the importance of the correct loading sequence here

    Product attributes

    Capacity 24-36 m³
    Discharge type Front discharge
    Model Trailed
    Strawblower No

    Choice of discharging units

      Explanation of abbreviations

      • VL = Front discharge
      • H = High discharge unit
      • L = Low discharge unit
      • B = Synthetic conveyor belt
      • K = Conveyor chain
      • C = Curved conveyor chain
      • ZK = Side discharge doors
      • X = Heavy Duty

      Share

      Photos

      Video

      Standard features

      • Two Heavy Duty Twin stream augers (22 mm flighting / 25 mm wings)
      • Two reversible restrictor blades
      • Wide-angle PTO-shaft with shearbolt (1 3/4" - 20 tractor connection)
      • Adjustable and reversible drawbar with 50 mm drawbar eye (European standard) (2400L)
      • Control by bowden cable
      • Reduction gearbox standard with cooling-system
      • Adjustable low drawbar with 50 mm drawbar eye (European standard) (2800-3600)
      • Tandem axle with 4 single wheels (2400L-3200) or 8 dual wheels (3600)
      • Wide discharge unit with conveyor belt or (curved) chain conveyor for discharge at both sides (B-C-S)
      • Wide chain conveyor with in height adjustable chain extension on right hand side (S)
      • Wear ring
      • Hydraulic brake system with parking brake
      • Trioform auger knives short
      • Dual Flow: improved shape of the mixing tub and offset inserts
      • Larger discharge door with rounded edges for better discharge
      • New stairs with platform and windows, in height adjustable arm for weighing indicator and guidance of hydraulic hoses with storage possibility
      • Two windows in discharge unit

      Technical specifications

      Solomix 2 VLX 2400L 2800 3200 3600*
      Capacity m3 24 28 32 36
      Length m 8,30 8,37 8,80 8,87
      Width m (excl. doseerunit) 2,66 2,66 2,80 3,00
      Height m 3,04 3,44 3,44 3,54
      PTO RPM 1000 1000 1000 1000
      Tractor power requirement HP (kW) 120 (88) 130 (95) 150 (110) 177 (130)
      Tyre size  435/50
      R 19.5
      4 x
      385/65
      R 22.5
      4 x
      385/65
      R 22.5
      4 x
      275/70
      R 22.5
      8 x


      * Model 3600 is not available in all countries, please ask your dealer.
      Alternative height dimensions are available on request. Ask your dealer about the available options.
