Triomatic HP suspended feeding robot
The Triomatic HP 2 300 is a suspended feeding robot. The robot moves around the building using a suspended rail system, which is particularly handy if the robot has to be kept clear of the floor in some parts of the building. This feeding robot can, in fact, be raised up in order pass over the cubical area if needed. This means the robot can also be used to scatter straw in the bedding area. Because the Triomatic HP 2 300 feeding robot is suspended from a rail, the surface conditions are not relevant and the system does not depend on the weather conditions in outdoor areas. The Triomatic feeding robot has two vertical mixing augers, a cross conveyor belt capable of discharging on both left and right, and a volume of 3 m3. In combination with a stationary feed mixer, a feed kitchen for blocks or bales, or storage bunkers for bulk feed, the feeding robot can be used as a fully automated feeding system. Wheel-based feeding robots are also available, such as the Triomatic WP 2 300 feeding robot on wheels.
Photos
Standard features
- 3 m3 mixing tub in wear-resistant stainless steel
- Two vertical mixing augers in wear-resistant stainless steel
- Cross conveyor belt capable of discharging on both the left and right
- Touchscreen and operating terminal
- All-electric drive
- Bumper protection
- Continuously variable speed control of the cross conveyor belt and mixing auger
- Trolley system with rubber-coated drive wheel
Technical specifications
| Triomatic | HP 2 300 |
|---|---|
| Capacity m3 | 3 |
| Length m | 3.60 |
| Width m | 1.35 |
| Net weight kg | 1.750 |
| Maximum payload kg | 900 |
| Min. track height m | 2.80 |
| Min. (net) feeding alley width m | 2.40 |
| Required connecting current A | 3x32 |
| Required voltage V~ | 400 |
| Max. standard track route gradient % | 2 |
| Max. extra track route gradient (with rack and pinion drive) % | 14 |
